Hydro-Grip G3 HSK 63F
ETP HYDRO-GRIP® G3 HSK 63F HYDRO-GRIP type G3 is historically very tough but the new generation has an even more compact design. The hydraulic chuck is equipped with our well known built in safety device. The safety device prevents the tool from falling out when the chuck is not pressurized. Pressurizing is carried out with an allen T-wrench. The G3 chuck allows quick, safe and easy tool changes and perfect runout and repeatability.
All Hydro-Grip products are currently sold on a Quote basis. Reach out to us: firstname.lastname@example.org or 440-462-0691 for pricing.
- World famous safety device
- Compact Design
- Quick, safe and easy tool change
- Perfect runout and repeatability
The type G3 chuck is designed and manufactured for a router bit shank with the tolerance g6 (h7). Transmittable torque for tools with tolerances:
Depth*= Clamping length
The runout is measured at 3xD and the max runout is ≤ 0,006 mm (0.00024 inch).
The type G3 chuck is balanced to G2,5 at 25000 rpm.
A normally balanced chuck and tool can be used up to a max. speed of 25000 rpm.
